Description

Deadweight 1300 mt on 2.6 m
Minimum sailing draft 1.3 m
Air draft 7,75 m
Bureau Veritas – Class 1
Deckship coastal
2 Azimuth thusters 400 kw each
1 bow thruster 400 kw
Speed abt 11 knts
Cargo deck:The cargo deck consists of 2 lifting platforms
Size of each platform : 2 x 25,10 m x 8,40 m
Max static load : 220 t per platform
Uniformily distribution load : 3 t / m²
Cargo deck sea position : 3,55 m / BL
A) upper position 4,80 m / BL
B) lower position 1,20 m / BL

Aft ramp : Breadth: 8,40 m
Length: 2,50m + flap 1,50m
LOA 75 m
Beam 13,8 m
Draft 2,6 m

Built in year 2004
Class : Bureau Veritas
Flag : Liberia
Gross Tonnage of 1.285 and Nett Tonnage of 385

Deadweight : 1.300 metric tonnes

Speed : 11 knots
Engines : 3 x Caterpillar / Caterpillar Inc, 2.400 kw, 1.500 rpm, Propellers 1 Directional (Port Side) + 1 Directional (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (1 Bow Tunnel thruster 400kw)

1 Deck

Specifications

Engine(s)

3 x 2.400 kw, 1.500 rpm, Caterpillar / Caterpillar Inc,
Propellers: 1 Directional (Port Side) + 1 Directional (Starboard)
