Description

LOA 73.6 m
Beam 16 m
Draft 5.89 m

Built in year 2010
Design is : UT 755-LN
Class : Registro Italiano Navale
Flag : Turkey
Gross Tonnage of 2,175 and Nett Tonnage of 1,059

Dynamic Positioning of class : DP 2
Free Deck area about 680m² with a deck strength of 5 metric tonnes per square meter
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 3 tons
Deadweight : 3,240 metric tonnes
Capable of supplies of 961m³ Fuel Oils, 831m³ FW, 993m³ Liquid Mud and 397m³ Brine

Total 22 berths
5 cabins with 1 berth
3 cabins with 2 berths
1 cabin with 3 berths
2 cabins with 4 berths

Speed : 11 knots
Engines : 2 x MaK / Caterpillar Motoren 6M25, 3,960 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 345 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster 590kw + 2 Stern Tunnel thruster 590kw)

Specifications

Engine(s)

2 x 3,960 kw, 750 rpm, MaK / Caterpillar Motoren 6M25,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
